- Robust and durable
- Built for comfort
- Increased travel speed
- High visibility mast
The strong and completely welded base frame is available with a choice of two basic fork widths and four different lengths to match demanding application requirements.
Seven models, from 1.4 to 2.5 tonnes, with a selection of four chassis lengths and more options, that are tailored to meet the demands of every indoor application. The three-piece design increases options and reduces replacement costs.
The precision-designed mast with unique channel comes with two options, Standard and heavy Duty available in 5 mast lift heights from 4,650mm to 12,750mm.
Excellent ‘through the mast’ visibility, stability and residual capacity is maintained to greater heights – enhanced h1:h3 ratio, lifting to a higher maximum level with a lower closed height.
|Model Name||Load Capacity||Load Centre||Lift Height||Platform Height||Turning Radius||AST (wide/long)||Battery Capacity||Overall Width||Weight||Engine||Transmission|
|R2.0HD||2000kg||12750mm||2850 / 2904mm||48V / 700-930Ah(V/Ah)||9755kg|
|R1.6N||1600kg||9000mm||2762 / 2811mm||48V / 420-775Ah(V/Ah)||6859kg|
|R1.6HD||1600kg||11400mm||2834 / 2896mm||48V / 560-775Ah(V/Ah)||8902kg|
|R2.0||2000kg||8150mm||2795 / 2835mm||48V / 560-775Ah(V/Ah)||7970kg|
|R1.6||1600kg||10500mm||2731 / 2767mm||48V / 420-775Ah(V/Ah)||6971kg|
|R2.5||2500kg||8150mm||2890 / 2915mm||48V / 700-930Ah(V/Ah)||8902kg|
|R1.4||1400kg||10500mm||2718 / 2764mm||48V / 280-620Ah(V/Ah)||6861kg|
